Feature: Callback URLs

Understanding Callback URLs

When you make a request to DigiTax API, we immediately return a response. The status of that transaction by default is pending because we save it into our queuing system to be relayed to the tax authority's system. Eventually, the status moves from pending to complete, and this is apparent via the DigiTax dashboard or when you make a GET request.

The tax authority's system or DigiTax may take some time to process a request, and it is not efficient to have you as the caller wait for a response. Callback URLs are useful since they inform you as soon as a particular event like a status change happens after data processing on the tax authority's system or DigiTax.

Where to use Callback URLs

We accept an optional callback_url property for both Add business item (POST) and Add invoice (POST) endpoints. More details under Scenarios section below.

During testing, we encourage you to use a site like webhook.site

Our system will POST data to the callback URL when we have new information about the item or sale, usually after syncing with the tax authority's system.

Scenarios

We send the following callbacks:

When an item has been synced to eTIMS, we send a POST request to the provided callback_url. The request body contains a data object with details about the synced item, and an event property with the value item.sync.
When a sale/ credit note has been synced to eTIMS, we also send a POST request to the callback_url. The request body contains a data object with details about the synced sale, and an event property with the value sale.sync.

Structure and examples

When an item has been synced to eTIMS

  {
    "data": {
      "item_class_code": "70101500",
      "item_type_code": "1",
      "item_name": "Water bottle",
      "origin_nation_code": "UG",
      "package_unit_code": "BA",
      "quantity_unit_code": "BG",
      "tax_type_code": "B",
      "default_unit_price": 900,
      "id": "<ITEM_ID>",
      "etims_item_code": "<eTIMS_ID>",
      "is_stock_item": true,
      "running_balance": 0
    },
    "event": "item.sync"
  }

When a sale/ credit note has been synced to eTIMS

  {
    "data": {
      "date": "01/02/2024",
      "time": "07:45:34 pm",
      "trader_invoice_number": "ACC-SINV-2022-00015",
      "original_invoice_number": "720001",
      "digitax_id": "<SALE_ID>",
      "serial_number": "<SERIAL_NUMBER>",
      "receipt_number": "17",
      "internal_data": "<INTERNAL_DATA>",
      "receipt_signature": "FGUWWXNHSOSKVDCI",
      "etims_url": "https://etims-sbx.kra.go.ke/common/link/etims/receipt/indexEtimsReceiptData?Data=P000000001G02FGUWWXNHSOSKVDCI",
      "sale_detail_url": "http://localhost:8080/sales/cls3g6np300028cegs6o8qw98",
      "customer_pin": "A123456789Z",
      "customer_name": "Test Customer",
      "queue_status": "completed",
      "invoice_number": "720005",
      "sales_tax_summary": {
        "taxable_amount_a": 0,
        "taxable_amount_b": -4655.17,
        "taxable_amount_c": 0,
        "taxable_amount_d": 0,
        "taxable_amount_e": 0,
        "tax_rate_a": 0,
        "tax_rate_b": -16,
        "tax_rate_c": 0,
        "tax_rate_d": 0,
        "tax_rate_e": -8,
        "tax_amount_a": 0,
        "tax_amount_b": -744.83,
        "tax_amount_c": 0,
        "tax_amount_d": 0,
        "tax_amount_e": 0
      }
    },
    "event": "sale.sync"
  }
